The challenge of total knee arthroplasty periprosthetic fracture: a comprehensive review

Department of Life Health & Environmental Sciences, University of L’Aquila, Unit of Orthopaedics and Traumatology, L’Aquila, Italy;
Department of Medical and Surgical Specialties and Dentistry, University of Campania “Luigi Vanvitelli”, Naples, Italy;
Unit of Orthopaedics and Traumatology, “S. Giuseppe Moscati” Hospital, Aversa, Italy;
Unit of Orthopaedics and Traumatology, AORN “S. Giuseppe Moscati”, Avellino, Italy;
Unit of Orthopaedics and Traumatology, AORN “S. Giuseppe Moscati”, Avellino, Italy;
Department of Medical and Surgical Specialties and Dentistry, University of Campania “Luigi Vanvitelli”, Naples, Italy;
Department of Medical and Surgical Specialties and Dentistry, University of Campania “Luigi Vanvitelli”, Naples, Italy;
Unit of Orthopaedics and Traumatology, Villa Malta Hospital, Sarno, Italy;
Unit of Orthopaedics and Traumatology, AORN “S. Giuseppe Moscati”, Avellino, Italy;
Unit of Orthopaedics and Traumatology, “S. Giuseppe Moscati” Hospital, Aversa, Italy;
periprosthetic fracture total knee arthroplasty revision retrograde nail plate fixation

Abstract

Total knee arthroplasty (TKA) is a common procedure in orthopeadic surgery. It has been estimated that the incidence of periprosthetic fractures after TKA ranged between 0.3 to 2.5%, but increases to 38% when considering revision TKA.
Patient-related risk factors for TKA periprosthetic fracture (TKAPF) include osteoporosis, age, female gender, revision arthroplasty and osteolysis. The choice of the most appropriate fixation device of TKAPF is a matter of debate, considering that locking plates and retrograde intramedullary are both associated with good outcomes in terms of fracture union and joint function.
In case of prosthetic component instability, severe comminution or metaphyseal extension of the fracture that precludes fixation, failure of previous treatments, and severe malalignment of the TKA, revision TKA (RTKA) should be considered. Severe bone loss is another issue of concern, that might be addressed using both megaprosthesis or allograft-prosthesis composite. Considering the variability of the clinical scenario of TKAPF, a comprehensive approach based on both fracture fixation and/or revision arthroplashty is needed.

Introduction

Total knee arthroplasty (TKA) is a common procedure performed in the elderly; considering the long life expectancy, and the age-related increasing of both osteoporosis and sarcopenia, the incidence of periprosthetic fractures around the knee is constantly growing up 1.

It has been estimated that the incidence of periprosthetic fractures after TKA ranges between 0.3 to 2.5% 2-4, but increase to 38% when considering revision TKA 4. The majority of these fractures occur between 2 to 4 years postoperatively and more often affect the distal femur (2%), compared to the proximal tibia (0.3-0.5%) 4. An important factor that acts in this field is the implant design 5. The intraoperative rate of periprosthetic TKA fractures is 4% 6, but it is probably underreported.

Several risk factors had been identidied including both patient- and surgical-related factors.

Patient-related risk factors for TKA periprosthetic fracture (TKAPF) are osteoporosis, age, female sex, revision and osteolysis 7. On the other hand, surgical-related risk factors are use of long tibial stems, cementless press-fit fixation, malalignment of the tibial component, tibial tuberosity osteotomy, and osseous defects in revision arthroplasty 5,8,9.

TKAPF in the elderly should be considered a life-threatening condition, as underlined in studies reporting a one-year mortality between 11 to 44.8% 10,11. Therefore, the objectivies of treatment should be similar to other fragility fractures: early mobilization and weight bearing in order to reduce the patient’s morbidity and mortality 12.

The treatment of TKAPF presents a relevant complication rate. A review of 415 cases reported a nonunion rate of 9%, fixation failure in 4%, an infection rate of 3%, and revision surgery in 13% 12.

The choice of the most appropriate fixation device of TKAPF is a matter of debate, considering that locking plates and retrograde intramedullary are both associated with good outcomes in terms of fracture union and joint function 13.

Moreover, considering the extreme variability of fracture pattern, a comprehensive approach to each case may be advisable.

In order to give a practical guide to the orthopedic surgeon in the treatment decision making of TKAPF we conducted a comprehensive review of the last 10 years on the treatment of this challenging condition.

Etiology and risk factors

TKAPF occurs most frequently in the supracondylar area of the femur 11,14, with a reported incidence of 0.3-2.5% after 2 to 4 years after surgery 15-17. Generally, these fractures are commonly observed around a well-fixed femoral component, after a low-energy trauma caused by torsional or compression forces 14,18.

Risk factors for the occurrence of a supracondylar TKAPF include prolonged steroid use, osteoporosis, rheumatoid arthritis, advanced age, female gender, neurologic disorders, anterior femoral notching, elastic modulus mismatch between the implant and the femoral cortex, rotationally inged implants, osteolysis, delayed bone remodeling due to vascular compromise at the surgical site, knee joint ankylosis, and previous revision TKA 14,15,19.

Anterior femoral notching refers to a defect of the anterior femoral cortex caused by excessive resection of the anterior femur during surgery. Several studies demonstrated that anterior femoral notching is closely associated with supracondylar TKAPF as it occurred in 10-46% of notched femurs 19,20. The mechanism through which anterior notching leads to TKAPF was studied by Culp et al. 19. The authors reported that a 3 mm anterior cortical notch results in a 30% reduction of torsional bone strength, thus increasing the risk of femoral fracture 19.

Interestengly, femoral fractures may also occur after navigation-assisted TKA at pinhole sites 20.

The prevalence of TKAPF around the tibial implant is relatively low (0.4-1.7%) 21,22.

TKAPF can occur throughout the entire procedure: from the bone cuts to the placement of the polyethylene insert 6,23.

However, TKAPF can be observed most commonly during joint exposure and bone cutting (39%) and trial components implantation (33%) 6. A phase at high risk is the removal of an implanted prosthesis during revision surgery 6,23. Some studies associated the preoperative neutral/valgus alignment with tibial fractures and tibial shaft fractures to tibial tubercle osteotomy 23.

Most postoperative fractures result from acute trauma, but stress fractures may also be observed 21.

In contrast to TKAPF around the femoral compontent, tibial fractures are often associated with component loosening or instability, as well as component malalignment, malpositioning, and joint instability 7. Rand et al. observed a malalignment of the knee joint or a tibial component malpositioning in all patients with stress fractures of the tibia following TKA 21. Lotke and Ecker 24 suggested that varus fixation of the tibial component was associated with medial plateau fracture. During TKA, care should be taken to not lateralise the tibial component excessively in patients with a history of high tibial osteotomy in order to avoid contact between the tibial stem and the lateral cortex of the tibia during implantation 25.

Diagnosis of TKAPF

If a fracture is suspected, long-leg radiography should be performed for confirmation. If pain is present without evidence of an obvious fracture or prosthesis loosening, blood tests, and joint aspiration should be performed to rule out infection 26.

Standard anteroposterior and lateral views are the basis of fracture analysis and classification. Before classifying the fracture, the stability of the prosthesis should be assessed evaluating the patient’s history before the trauma (a history of pain around the prosthesis may indicate previous loosening) and conventional X-ray 27.

Typical signs of loosening, like shield displacement from the distal femur or separation of cement, might be detected. In ambiguous cases, a CT-scan may help find signs of loosening, particularly around the femoral component 27.

However, to diagnose a loosing implant can be extremely hard, particularly in case of TKAPF, a condition in which prosthetic loosening might be partial. Therefore, the surgeon should be prepared to perform a revision arthroplasty, even though an osteosynthesis was initially planned.

Sometimes, septic loosening may precede the TKAPF. Therefore, laboratory tests (eg. ESR, CRP) and analysis of the intraarticular fluid for white blood cells and bacteria is recommended in patients with suspicion of infection 26.

Classification

Several classification systems have been proposed for both femoral and tibial TKAPF.

One of the mostly used is that proposed by Rorabeck and Taylor for femoral fracture 17 in 1998. This classification considers implant fixation status and fracture displacement.

Su et al. 2, instead, suggested a classification system based on the relationship of the fracture line with the femoral component.

More recently, Kim et al. 27 proposed a classification based on periprosthetic bone stock, prosthesis stability, and reducibility of the fracture.

Regarding the tibial periprosthetic fracture the most commonly used classification system was the one suggested by Felix et al. 22. According to these authors, periprosthetic fractures around the tibia can be categorized into four types (I-IV) and three subtypes (A, B, C) depending on the anatomical location of the fracture and the tibial component fixation. See Table I for further details.

Treatment

The treatment of TKAPF should promote fracture union and joint function recovery. Acceptable alignments after fracture reduction are < 5 mm translation, < 5°-10° angulation, < 10° rotational deformity, and < 1 cm femoral shortening 28. In case of severe fracture displacement, comminution, or intercondylar extension, it can be difficult to obtain satisfying functional outcomes.

In addition, the action of adductor and gastrocnemius muscles may cause fracture malunion, leading to varus, flexion and internal rotation deformities of the distal fragment. Figgie et al. 16 reported a progressive radiolucent lines at the bone-cement interface in 9 of the 12 femoral supracondylar TKAPF with a varus malunion.

Non-operative treatment, which includes skeletal traction, splinting, casting, and bracing, might be advantageous in patients who cannot undergo surgery.

In this cases, if a fracture reduction is considered necessary, closed reduction is followed by 4-6 weeks of cast immobilization, during which the alignment of the fracture and implant stability are regularly monitored through radiographs performed every two weeks.

In a knee with a normal component alignment and stable prosthetic fixation and minor displacement of the fracture, closed reduction and cast immobilization can provide acceptable results 22.

Femoral fracture

For unstable, displaced fractures, reduction and fixation obtained with operative treatment allow early range of motion and ambulation 14,15. Common surgical techniques include both external fixation and internal fixation (i.e. blade plates, condylar screws, retrograde intramedullary nails or locking plates) and revision TKA.

Internal fixation with metal plates

Some internal fixation devices, such as 95° angled blade plates, dynamic condylar screws, and condylar buttress plates, do not provide stable fixation for comminuted supracondylar fractures with poor bone stock and could interfere with the femoral component or cement 16,27,29. Substantial effort had been made to identify a method that ensures rigid fixation in the osteopenic bone using bone grafting or bone cement augmentation. Healy et al. treated 20 Rorabeck type II fractures using blade plates and condylar screw plates, with the addition of bone grafting in 15 knees with severe osteoporosis 30. The fractures healed in all knees, although revision surgery was required due to loss of reduction in two knees 30.

Another critical issue of traditional plating of supracondylar fractures is the varus collapse in case of severe comminution. In these latter scenario, dual plating might be considered to prevent the secondary varization of the femur associated with single lateral traditional plating 31.

Locking plates are fixed-angle devices designed to engage with the screw threads 32. These plates assure a more rigid fixation compered with traditional metal plates for periarticular, comminuted, and osteoporotic fractures 28,32.

A theorical disadvantage of internal fixation with plates includes the need for large surgical exposure with extensive soft tissue damage that could lead to an increased risk of nonunion due to damage to the periosteum and blood vessels. The availability of the anatomically shaped locking plates opened to a new implantation technique known as minimally invasive percutaneous plate osteosynthesis (MIPO) (i.e.: less invasive stabilization system [LISS]). This technique allows minimizing injury to the adjacent soft tissue and periosteum, thus promoting rapid bone union with a low risk of complications compared to traditional techniques 28,33. Some locking metal plates allow for closed reduction with use of percutaneous screw insertion or a retractor based on the principle of ligamentotaxis 33. Kregor et al. performed LISS fixation for the treatment of supracondylar fractures and obtained bone union in 36 of 38 knees without any complications 34.

However, the use of locking plates for distal femoral fractures is still debated, because of the reported healing problems and complications. In particular, a nonunion rate ranged from 0 to 19%, a delayed unions ranged from 0 to 15%, and an implant failures ranged from 0 to 20% were reported 35. In order to improve patients outcomes, a careful preoperative planning is needed when choosing a locking plate, to identify the correct plate length, fixation working length, and screw distribution 35.

Retrograde intramedullary nailing

Retrograde intramedullary nailing (RIN) is recommended for TKAPF over anterograde nails, also considering the difficulties in obtaining the distal locking of the latter 36. Compared to conventional plate fixation, RIN is associated with less soft tissue damage and blood loss. In addition, the preservation of periosteal blood supply and fracture hematoma promotes bone union.

Currently used interlocking intramedullary nailing takes advantage of interlocking screws that allow higher resistance to axial compression and torsional forces. RIN of Rorabeck type II supracondylar femoral fractures yields high union rates and excellent functional outcomes 37. RIN should be long enough to reach the level of the lesser trochanter, considering that the engagement of the isthmus prevents a windshield wiper effect and improves stability 38. Hyperextension of the femoral component may occur in the sagittal plane because reaming and insertion are performed with the knee in flexion position and can be more evident if the insertion site is posterior to the intercondylar notch. According to Pelfort et al., hyperextension of the femoral component does not significantly affect stability of the prosthesis, bone union, or knee joint function 39. Valgus malalignment of the distal fragment in the coronal plane is often encountered. To avoid this, it is recommended to use a blocking screw as a guide for proper insertion of the intramedullary nail 40.

Before performing a RIN osteosynthesis, the surgeon must be aware of the shape of the femoral component of the impanted TKA, to be sure that the distal entry point between the condyles is ‘opened’. In fact, TKA with a box (e.g. posteriorly stabilized) or with a stem cover the RIN entry point. In this case, a plate might be used 36.

Contraindications to intramedullary nailing include patellar baja, joint ankylosis precluding intramedullary nail insertion, < 11 mm intercondylar distance or narrow medullary cavity, preexisting intramedullary stem in the proximal femur from previous total hip arthroplasty, severe comminution or extremely distal fracture precluding stable internal fixation and unstable TKA prosthesis 38-40.

Revision total knee arthroplasty

Revision TKA (RTKA) should be considered in case of femoral component instability (regardless of the degree of fracture comminution and displacement) 14,15,29,41, severe comminution or fracture periarticualar extension that precluding internal fixation, failure of previous treatments, and severe malalignment of the TKA 14,15,19,41.

During revision TKA, a long-stemmed femoral component is inserted through the fracture site into the proximal femur overcoming the fracture site 15,16,19,29. Although cemented femoral components are commonly used, if fracture stability cannot be obtained using only the long stem, strut allograft or cerclage wiring should be used to improve stability of both the fracture and the femoral component 16,29. If nonunion occurs due to the lack of bone stock, distal femoral replacement using a megaprosthesis may be considered as a limb salvage procedure to preserve minimum knee function and maintain the length of the leg 42. Freedman et al. reported that distal femoral replacement performed using a tumor megaprosthesis due to nonunion and comminution following internal fixation of periprosthetic supracondylar fractures resulted in early ambulation and 100° of range of motion in 4 of 5 knees 42.

A high complication rate for distal femur megaprosthesis has been reported. Mortazavi et al. observed an overall complication rate of 50% and a reoperation rate of 22.3% 43. The complications included infection, fractures around or above the femoral prosthesis, and femoral component loosening 11. Berend and Lombardi reported a complication rate of 18%, a reoperation rate of 13.5%, and an infection rate of 8% 44. In contrast, Saidi et al reported no complications and Girgis et al. a complication rate of 14.2% 45,46. Of note, the reported mortality rate of distal femur periprosthetic fractures treated with revision arthroplasthy is high. Hoellwarth et al. reported a 4% mortality rate at 90 days and 10% mortality rate at 1 year 47.

Tibial fracture

The treatment of severely displaced, unstable periprosthetic tibial fracture can be perfomed using open reduction and internal fixation. Plates are commonly used for internal fixation because the preexisting tibial component precludes insertion of intramedullary nails 6,22. Even in a knee with poor bone stock, locking plates with several locking screws inserted around the tibial stem allow rigid fixation. In cases of intraoperative fractures, treatment decisions are based on the status and site of the fracture. For unstable type IC fractures, screw fixation of bone fragments is followed by insertion of a long-stemmed tibial component through the fracture site to the tibial medullary cavity. Type IIC fractures are treated using a long-stemmed tibial component and bone graft for bone defects at the fracture site. Type IIIC fractures are managed with either internal fixation or conservative treatment based on the fracture site and pattern 6. Type IV fractures that involve the tibial tubercle should be treated with care to avoid disruption of the extensor mechanism. Felix et al. 22 obtained bone union without any complication in 2 type IVA fractures after cast immobilization with knee extension in one case and screw fixation in the other case. Hanssen and Stuart suggested the use of polypropylene mesh tape or semitendinosus rerouting for fixation of tibial bone fragments in cases of type IV fractures 48.

The thin layer of soft tissue overlying the tibia predisposes to soft-tissue complications. Ideally, fixation of these fractures is achieved via a limited open approach proximally, that facilitates fracture reduction, and a MIPO for the insertion of the plate to preserve the local blood supply of the limited soft tissue 36.

Platzer et al. reviewed outcomes of 41 periprosthetic fractures after TKA 49. Of these 41 fractures, 4 were in the tibia (1 Felix type IA, 2 Felix type IIA, 1 Felix type IVA). The Felix type IA fracture was managed nonsurgically, and the other three were managed with plate fixation 49. Nonunion developed in one of the three proximal tibial fractures managed with plate fixation. The other three fractures healed successfully within 6 months after intervention 49.

Haller et al. suggested a technique for implantation of an IM nail for management of four Felix type IIIA periprosthetic tibial fractures 50. Their proposed technique included the use of a more distal transpatellar entry point, hand reaming of the proximal tibia part adjacent to the implant, the use of a suction tip to navigate the guidewire past the posterior cortex, the insertion of a nail with a diameter of 9 mm, and bending the nail with a bending press. At final follow-up (mean, 14.3 months), all four fractures had achieved union and all patients had returned to baseline function 50.

If the tibial component is unstable, revision TKA should be considered 18,21,22. In revision TKA, the tibial component fixation should use a longer stem, in order to overcome the fracture site of the proximal tibia 14,21,22. After tibial component fixation, additional internal fixation may be required for the remaining unstable bone fragments. Any bone defects in the proximal tibia should be treated using metal augmentation. These latter units with thick polyethylene insertion can be effective for treating ≤ 5 cm deep bone defects. More severe bone defects or comminuted fractures should be managed using either strut allograft or tumor megaprosthesis 48.

Subtype B periprosthetic tibial fractures should be managed with a revision TKA with a long-stem tibial component 51,52. Abbas and Morgan-Jones reviewed revision TKA in six patients with nonunion and malunion 52. At final follow-up, all patients were ambulatory and exhibited significant improvement in mean range of motion and Oxford Knee Score 52.

Bone allograft was a successful augmentation in the reconstruction of periprosthetic tibial fractures with a massive bone defect 53. Ghazavi et al. used a long-stem tibial component with bone allograft in three periprosthetic tibial fractures with bone defects over 3 cm in length 54. At a mean follow-up of 50 months (range, 24 to 132 months), the results were successful in all three cases in terms of bone union at the allograft-host junction and functional score 54.

Megaprostheses are rarely indicated in the management of periprosthetic tibial fractures because of the challenge of reestablishing the insertion of the extensor mechanism 55. Type IB fractures with severe comminution or major cortical destruction secondary to osteolysis are the only indication for reconstruction with megaprostheses 22,55. Windhager et al. reviewed the use of megaprostheses in 11 patients with periprosthetic fractures of the knee 55. Only one of these patients had a periprosthetic tibial fracture (type IB) 55. After 62-months of follow-up, the patient had no pain and a Medical Outcomes Study 12-Item Short Form score of 42. In their review of the literature, Windhager et al. found that revision rates associated with megaprostheses ranged from zero to 55%. Most revisions were performed because of mechanical factors or infection 55.

Conclusions

TKPFA are a challenge for the orthopedic surgeon. Undisplaced fractures with well fixed implants can be treated with plate fixation or intramedullary nailing, when possible (i.e. cruciate sparing TKA or Felix type III tibial fractures).

In case of poor bone stock, comminution, severe osteoporosis, or prosthesis loosening, a revision arthroplasty is required, also using mega-prosthesis or composite implant.

Considering the high rate of complications and extreme variability of the surgical scenario, the orthopedic surgeon should be able to use all available fixation tecniques and perform a revision arthroplasty. Therefore, a high specialized surgical team and comprehensive equipment is needed to improve patient outcames.

Figures and tables

Figure 1.A Rorabeck Type I in a 74-year-oldfemale (A). The patient was treated using a locking plate through a MIPO technique (B). C) Antero-posterior X-ray at 3 months after surgery showing fracture healing.

Figure 2.A,B) A TKAPF around a revision arthroplasthy occurred in a 71-year-old female involving both the femur (Roraback type 3) and the tibia (Friser type 2). Considering the poor bone stock and the patient’s age, a mega-prosthesis was used. (C,D,E,F). In G and H, antero-posterior and lateral x-ray at 1 year of follow-up. The patient was able to walk without aid.

Figure 3.A,B) A 65-year-old female who developed a nonunion after a TKAPF treated with with plate and screws. Note the poor bone stock in the distal femur and fracture malalignment. The patient was treated using an allograft-prosthesis composite (C). In D, antero-posterior and lateral x-rays at 1 year after the surgery. Note the allograft osteointegration.

Femur fracture
Rorabeck and Taylor 17 Su et al. 2 Kim et al. 27
Type I Non-displaced fracture around a well-fixed prosthesis Fractures are proximal to the femoral component Fracture that occurs in the knee with an intact prosthesis and sufficient bone stock
Type II Fractures have ≥ 5 mm displacement or ≥ 5° angulation with the prosthesis remaining stable; into type IIA (non-comminuted fractures) and type IIB (comminuted fractures) Fracture lines originate at the proximal end of the femoral component and partially extend proximally Revision surgery is required due to unstable fixation or malposition of the prosthesis in spite of sufficient bone stock and reducibility
Type III Fracture is accompanied by component loosening/instability and polyethylene wear irrespective of the displacement of fracture fragments Fractures occur distal to the upper edge of the femoral component Severely comminuted facture with poor bone stock
Tibial fracture
Felix et al. 22
Type I Fractures are located at the tibial plateau
Type II Fractures occur inferior to the tibial plateau adjacent to the prosthetic stem,
Type III Fractures occur distal to the tibial stem
Type IV Fractures involve the tibial tubercle
Type A Fracture with a stable prosthesis on radiographs
TypeB As fractures with radiographic evidence of component loosening
Type C Intraoperative fracture
Table I.Classification systems of femoral and tibial TKAPF.
