Trauma Meeting
Published: 2021-04-27

Current evidence and new challenges in periprosthetic hip and knee fractures

ASST Gaetano Pini - CTO, Orthopaedic Institute, Milan, Italy;
ASST Gaetano Pini - CTO, Orthopaedic Institute, Milan, Italy;
University of Milan, Milan, Italy
University of Milan, Milan, Italy
ASST Gaetano Pini - CTO, Orthopaedic Institute, Milan, Italy; University of Milan, Milan, Italy
hip knee femur tibia periprosthetic fracture

Abstract

Periprosthetic fractures (PPF) constitute an issue of increasing importance for orthopedic surgeons. With the continuous advancement of less invasive surgery techniques and the progressively ageing population, prosthetic replacement procedures have become routine. PPF are complex conditions that can compromise the outcome of surgery and the patient’s quality of life. However, in some cases, revision surgery is required. In this article we will analyze the epidemiology, risk factors, different classi ications, management, and evolution of treatment of hip and knee periprosthetic fractures.

Introduction

The overall number of periprosthetic fractures (PPF) is rising, due to three main risk factors: the increasing number of total hip and knee replacements being performed in Western countries and the global median age combined with the prevalence of bone weakening pathologies in elderly patients 1.

Intraoperative periprosthetic fractures occur 14 times more frequently with un-cemented implants than with cemented ones, especially in patients over 65 years of age. Much more often, however, fractures occur in un-cemented prostheses because of low-energy trauma, regardless of gender 2. The difficulty of treatment depends not only on fracture management, but above all on the stability of the prosthesis.

Furthermore, general and local factors can play an important role. General conditions, functional requests, patient compliance, and comorbidities are extremely important and must be taken into account. Local factors consist in the intraoperative stability of the implant, bone stock, and biology of the bone. In case of elderly patients with other pathologies, who poorly comply with their therapeutic and rehabilitative plan, choosing the least invasive type of procedure is preferred. Very often, however, in order to avoid complications due to extended bed rest and allow early load, prosthetic replacement is the surgical choice. For young patients, bone stock preservation is imperative, in consideration of their long-life expectancy and the high probability of a revision 3.

Epidemiology

In total hip arthroplasty (THA) the incidence of PPF varies from about 1 to 2.3% and is higher when using un-cemented prostheses instead of cemented ones (3 vs 0.2%); for women, compared to men, these percentages increase over the years. In THA revisions, the total incidence is even higher at 12.3% 2,4.

In total knee arthroplasty (TKA), the incidence of PPF varies between 0.3 and 2.5% for the first implants and increases up to 38% after revision, with an average of 25.5 months between the TKA and possible fracture 5,6.

The mortality rate following a femur PPF is significantly higher compared to a simple femur fracture. The increase in mortality affects both THA and TKA and is higher after surgery, reaching 8% in the first post-operative month and 27% after the first year. Survival decreases in older patients 2,7.

Risk factors

Numerous factors can predispose to PPF. Patient-associated factors include advanced age, female gender, neurological and walking disorders, and more generally all conditions causing a depletion of bone mass such as osteoporosis, osteomalacia, Paget’s disease, and osteopenia due to corticosteroid therapy 1. Prosthetic-related factors include local bone resorption and osteolysis phenomena, which can occur as a result of implant mobilization and bone defects 8.

Classification

PPF are generally categorized and classified based on the fracture site, but the classification can also take into account other criteria. For instance, how long after the prosthetic replacement surgery the fracture occurred and the stability of the implant 9.

The Vancouver classification for Periprosthetic Hip Fractures is the universal reference and is based on the fracture site and type, stability of the implant, quality of the periprosthetic bone stock (Tab. I) 10,11.

There are several classifications for periprosthetic knee fractures and the most widely used is Rorabeck and Taylor. It evaluates fractures of the femoral component and takes into account bone fragment displacement and stability of the prosthetic components, but does not evaluate bone stock quality (Tab. II) 12.

Felix’s classification concerns PPF of the tibial component, although less frequent, and divides them into four categories (Tab. III).

Patella fractures are categorized following the Goldberg classification, which is based on the integrity of the extensor apparatus and stability of the patella surface 14.

Periprosthetic hip fracture

There are currently no defined guidelines for the treatment of hip PPF. The choice of treatment depends on the type of fracture according to the Vancouver classification 2.

In general, the loss of bone stock and the general conditions of the patient, often compromised, makes surgery more difficult. Revision surgery is basically inevitable in case of high comminution fracture or loosened prostheses 15,16.

The implant stability is evaluated both by CT scan and intraoperatively. The proposed treatments are, therefore, open reduction and internal fixation (ORIF) or revision 7.

Generally speaking, there is unanimity in defining internal fixation as the treatment of choice for B1 fractures and revision as the best treatment for B2, B3, and C fractures, whereas most AG-type fractures are avulsions of the greater trochanter which are treated conservatively 2,17,18.

After the surgery, the aim is to reduce bed rest time in order to minimize complications, allowing fast functional recovery. The most frequent complications are: non-union, fracture recurrence, aseptic loosening, recurrent dislocations, local infections, post-surgical stiffness, and limping 2,17,19.

Periprosthetic knee fracture

As for fractures of the proximal femur, there are no precise indications regarding management of distal femur fractures in patients with TKA 6. The conservative treatment of supracondylar fractures is based on skeletal traction and immobilization of the limb. Skeletal traction is hard to implement because it requires prolonged immobilization and can lead to local and systemic complications, such as pressure ulcers and thromboembolic events. For these reasons, it is no longer in use 20.

The most used surgical osteosynthesis techniques for supracondylar fractures are plate and screw synthesis and intramedullary nailing 6. In this case, early patient mobilization is essential to minimize complications associated with internal fixation, among which non-union stands out 21,22.

In patients with low bone stock or significant bone loss, obtaining a stable fracture synthesis is not possible, and therefore the use of megaprostheses should be considered. The use of this technique allows the patient to gain early weight bearing, recovery of an acceptable range of motion, and a better long-term result, despite an increased rate of post-operative complications and mortality 23,24.

Tibial fractures are a minority of periprosthetic knee fractures with a prevalence of 0.07-0.1% 25. Tibial plateau fractures generally cause loss of implant stability and are treated with revision arthroplasty, while fractures without mobilization can be treated with open reduction and internal fixation (ORIF) 26.

Methods

For the purpose of this study, we searched the PubMed and Cochrane databases with “periprosthetic fractures, femur, tibia, hip, knee, revision, megaprosthesis” as keywords. We crossed referenced the current insights on periprosthetic fracture treatment with our personal experience, to produce a review of the existing literature about treatment and management of PPF.

Results

By analysis of literature data about treatment of proximal femur PPF, the most common fracture is the Vancouver B1 type. The average age of patients according to Cox et al is 76.6 years; 1-2% of periprosthetic hip fractures were treated conservatively, 70% with ORIF and 27% with revision. Hospital mortality rate was 2.6% 4.

According to Abdel et al., the rate of PPF is much higher in cases treated with un-cemented implants than with cemented ones (7.7 vs 2.1%). 82% of AG-type fractures are avulsion fractures of the greater trochanter and 89.7% of these cases were treated conservatively. Among B1 fractures, 77% are treated with ORIF. Among fractures of types B2, B3, and C, 94.2% of cases were treated with THA revision 2,28. In cases of type B2 and B3 fractures, the most recent studies show that ORIF and the prosthetic revision are comparable in terms of results 27. It should be noted that a prosthetic replacement of the proximal femur, with massive bone loss, brings about an infection rate of around 2% and a percentage of instability close to 19% 29.

For periprosthetic knee fractures, the average age is 70-76 years. Rorabeck type II fracture is the most frequent, followed by Rorabeck III and I 30. According to Herrera et al, angular-stable plates give better long-term results than traditional plates. The medullary nail provides better fracture reduction but, in long-term follow-up, has a higher rate of pseudo-arthrosis than plate fixation 31. Several studies have observed that, the surgical treatment success rates of Rorabeck Type II fractures for patients treated with locking plate systems are similar to that of patients treated with intramedullary nail, respectively reaching 87 and 84% 32-34. Other studies, however, have shown better results when using locking plate system 35. Megaprostheses are a valid choice in distal femur PPF, especially if comminuted with bone stock loss; periprosthetic infections are the main complication 36.

Analyzing comminuted fractures of the distal femur, Darrit B. et al pointed out that there is no significant difference in terms of blood loss between ORIF and prosthetic replacement. Moreover, multivariate analyses showed that the mortality rate of the two groups appeared to be overlapping 37. However, Saidi et al. concluded in their study that blood loss and recovery time are reduced when revision surgery was performed 38.

Discussion

Considering the increased incidence, long-term consequences, and increased mortality rate, hip and knee PPF constitute an issue of increasing importance for orthopedic surgeons. Currently used osteosynthesis systems represent an evolution in the treatment of this type of fracture. Locking plate systems preserve periosteal vascularization, allow minimally invasive techniques, and give better stability in poor bone stock compared to conventional plating systems. Low contact plates respect bone biology and minimize soft tissue damage. The load is distributed from the screw to the plate allowing for both compression and/or angular stability (depending on the surgeon’s choice and the fracture type). However, callus formation is sometimes inconsistent and asymmetrical, so that their use can cause delayed union and pseudo-arthrosis. As stated by Bottlang et al., the high stiffness of the angularly stable plates reduces micro-movements around the fracture site, reducing callus formation 39.

Far cortical locking (FCL) screws can be seen as a new frontier in traumatology. Combined with locking plates, FCL screws show greater elasticity of the construct, promoting callus formation 40. Moazen et al. demonstrated in 2016 that FCL screws guarantee and increase fracture site micro-movements, but also the stability of the PPF synthesis under axial and torsional loads. Therefore, their use is recommended in case of stable fractures (possibly with 1 mm gaps between each fracture fragment). However, other methods of synthesis such as long revision stems are advisable in case of PPF with unstable implant 41.

Prevention is a continuous process, starting from the first implant surgery, and then with post-operative radiographic checks to be repeated over the following months. When PPF occur, the primary objective of treatment must be functional rehabilitation for rapid recovery of the patient, in order to ensure implant stability and reduce mortality.

Although the literature does not present a precise and defined management algorithm for these cases, the use of classifications that take into account various aspects is crucial.

When choosing to proceed with ORIF, the principles that must be respected are stable fixation, preservation of soft tissues, and careful pre-operative planning (Fig. 1).

The use of resection prostheses or megaprostheses, in cases with large bone loss and highly comminuted fractures, is a possible choice. However, we would like to point out the importance of having a team of experienced surgeons, accustomed to using this type of implant and to filling large segmental defects (for example in oncological orthopedic surgery) (Fig. 2) 42.

For the distal femur, there is no significant difference in terms of function, considering the Knee Society Score 37, for fractures treated with prosthesis instead of ORIF. Very often, distal femur fractures, or in any case of fractures involving the joint component, even when treated with ORIF, the result is a severe osteoarthritis which in most cases subsequently requires a prosthetic implant.

The complexity of using resection prostheses or megaprosthesis is complex, and many cases of severe complications are described in the literature, which are often hard to manage. There is a high incidence of dislocations in proximal femur replacements. On the contrary, a high rate of infections is reported in distal femur replacements 36. Choosing replacement surgery with this type of implant means having to deal with very severe complications to which traumatologists are often not accustomed.

Taking into account to all the above, choosing the right course of action among all the available surgical treatment options is a difficult task, since conservative treatment is not always to be preferred and, in selected cases, it would be appropriate to consider using megaprosthesis.

In addition to improving megaprosthetic skills, the current challenges involve treating fractures in patients who have already undergone treatment of a PPF using ORIF; for example, patients with THA and proximal plate and screws. Our experience has led us to treat cases such as the aforementioned through the use of classic plates modeled preoperatively on the anatomy of the bone segment to be synthesized (Fig. 3).

In other cases, when inter-prosthetic fracture occurs combined with the presence of an ipsilateral THA and TKA, Patel NK et al. suggest to proceed with a reconstruction technique, by using a custom-made megaprosthesis that allows direct attachment to the stem of the retained knee prosthesis 43.

Conclusions

The management of PPF represents a complex challenge. In fact, there is currently no clear boundary between synthesis and revision. The choice is influenced by several factors and the various classifications constitute a valid support, but are not completely sufficient to choose the most suitable surgical procedure. The use of megaprostheses in multi-fragmented and comminuted fractures with bone loss is a viable option, but surgeons must be familiar with surgical techniques and implants. Nowadays, the types of treatment for standard fractures have reached unambiguous indications, as opposed to PPF which require further advancement in terms of approach and treatment. In the most complex cases, such as fractures adjacent to prior PPF, the new perspective should include megaprostheses or, alternatively, advanced and patient-specific techniques of synthesis.

Figures and tables

Figure 1.Revision surgery in a failed ostheosynthesis of a periprosthetic fracture.

Figure 2.Distal femur replacement with a megaprosthesis in a failed osteosynthesis of periprosthetic fracture.

Figure 3.Classic plates modeled preoperatively on the anatomy of the bone segment to be synthesized.

Classification Fracture location Treatment
A AG Greater trochanter fracture Non-operative or ORIF
AL Lesser trochanter fracture Non-operative or ORIF
B B1 Fracture around the prosthesis, stem well fixed ORIF
B2 Fracture around the prosthesis, stem is loose Revision arthroplasty
B3 Fracture around the prosthesis, loose stem and poor proximal bone stock Revision arthroplasty
C Fracture distal to tip of stem ORIF
Table I.Vancouver classification.
Type Fracture Treatment
I Non-displaced fracture Prosthesis is intact Non-operative
II Displaced fracture Prosthesis is intact Internal fixation
III Non-displaced or displaced fracture Prosthesis is loose or failing Revision
Table II.Rorabeck and Taylor classification (from Rorabeck, Taylor, 1999, mod.)5.
Type Fracture
I Fracture of tibial plateau
II Fracture adjacent to tibial stem
III Fracture of tibial shaft, distal to component
IV Fracture of tibial tubercle
Table III.Felix classification (from Benkovich et al., 2020, mod.)13.

References

  1. Eschbach D, Buecking B, Kivioja H. One year after proximal or distal periprosthetic fracture of the femur – two conditions with divergent outcomes?. Injury. 2018; 49:1176-1182. DOI
  2. Abdel MP, Watts CD, Houdek MT. Epidemiology of periprosthetic fracture of the femur in 32 644 primary total hip arthroplasties: a 40-year experience. Bone Joint J. 2016; 98-B:461-467. DOI
  3. Solomon LB, Hussenbocus SM, Carbone TA. Is internal fxation alone advantageous in selected B2 periprosthetic fractures?. ANZ J Surg. 2015; 85:169-173. DOI
  4. Cox JS, Kowalik TD, Gehling HA. Frequency and treatment trends for periprosthetic fractures about total hip arthroplasty in the United States. J Arthroplasty. 2016; 31:115-120. DOI
  5. Rorabeck CH, Taylor JW. Periprosthetic fracture of the femur complicating total knee arthroplasty. Orthopedic Clinic. 1999; 30:265-277.
  6. Ebraheim NA, Kelley LH, Liu X. Periprosthetic distal femur fracture after total knee arthroplasty: a systematic review. Orthop Surg. 2015; 7:297-305. DOI
  7. Drew JM, Griffin WL, Odum SM. Survivorship after periprosthetic femur fracture: factors affecting outcome. J Arthroplasty. 2016; 31:1283-1288. DOI
  8. Giaretta S, Momoli A, Porcelli G. Diagnosis and management of periprosthetic femoral fractures after hip arthroplasty. Injury. 2019; 50:S29-S33. DOI
  9. Legosz P, Platek AE, Rys-Czaporowska A. Correlations between Vancouver type of periprosthetic femur fracture and treatment outcomes. J Orthop. 2019; 16:517-521. DOI
  10. Masri BA, Meek RM, Duncan CP. Periprosthetic fractures evaluation and treatment. Clin Orthop Relat Res. 2004; 420:80-95.
  11. Menken LG, Rodriguez JA. Femoral revision for periprosthetic fracture in total hip arthroplasty. J Clin Orthop Trauma. 2019; 11:16-21. DOI
  12. Konan S, Sandiford N, Unno F. Periprosthetic fractures associated with total knee arthroplasty: an update. Bone Joint J. 2016; 98-B:1489-1496. DOI
  13. Benkovich V, Klassov Y, Mazilis B. Periprosthetic fractures of the knee: a comprehensive review. Eur J Orthop Surg Traumatol. 2020; 30:387-399. DOI
  14. Goldberg VM, Figgie HE, Inglis AE. Patellar fracture type and prognosis in condylar total knee arthroplasty. Clin Orthop Relat Res. 1988;115-122.
  15. Sheth NP, Brown NM, Moric M. Operative treatment of early peri-prosthetic femur fractures following primary total hip arthroplasty. J Arthroplasty. 2013; 28:286-291. DOI
  16. Moore RE, Baldwin K, Austin MS. A systematic review of open reduction and internal fixation of periprosthetic femur fractures with or without allograft strut, cerclage, and locked plates. J Arthroplasty. 2014; 29:872-876. DOI
  17. Hoffmann MF, Lotzien S, Schildhauer TA. Outcome of periprosthetic femoral fractures following total hip replacement treated with polyaxial locking plate. Eur J Orthop Surg Traumatol. 2017; 27:107-112. DOI
  18. Pires RE, de ToledoLourenço PR, Labronici PJ. Interprosthetic femoral fractures: proposed new classification system and treatment algorithm. Injury. 2014; 45:S2-6. DOI
  19. Abdel MP, Cottino U, Mabry TM. Management of periprosthetic femoral fractures following total hip arthroplasty: a review. Int Orthop. 2015; 39:2005-2010. DOI
  20. Lombardo DJ, Siljander MP, Sobh A. Periprosthetic fractures about total knee arthroplasty. Musculoskelet Surg. 2020; 104:135-143. DOI
  21. Streubel PN. Mortality after periprosthetic femur fractures. J Knee Surg. 2013; 26:27-30. DOI
  22. Campbell ST, Lim PK, Kantor AH. Complication rates after lateral plate fixation of periprosthetic distal femur fractures: a multicenter study. Injury. 2020; 51:1858-1862. DOI
  23. Saidi K, Ben-Lulu O, Tsuji M. Supracondylar periprosthetic fractures of the knee in the elderly patients: a comparison of treatment using allograft-implant composites, standard revision components, distal femoral replacement prosthesis. J Arthroplasty. 2014; 29:110-114. DOI
  24. Windhager R, Schreiner M, Staats K. Megaprostheses in the treatment of periprosthetic fractures of the knee joint: indication, technique, results and review of literature. Int Orthop. 2016; 40:935-943. DOI
  25. Felix NA, Stuart MJ, Hanssen AD. Periprosthetic fractures of the tibia associated with total knee arthroplasty. Clin Orthop Relat Res. 1997; 345:113-124.
  26. Kim H-J, Park K-C, Kim J-W. Successful outcome with minimally invasive plate osteosynthesis for periprosthetic tibial fracture after total knee arthroplasty. Orthop Traumatol Surg Res. 2017; 103:263-268. DOI
  27. Stoffel K, Blauth M, Joeris A. Fracture fixation versus revision arthroplasty in Vancouver type B2 and B3 periprosthetic femoral fractures: a systematic review. Arch Orthop Trauma Surg. 2020; 140:1381-1394. DOI
  28. Franceschini M, Barbera L, Anticonome A. Periprosthetic femoral fractures in sideways fall configuration: comparative numerical analysis of the influence of femoral stem design. Hip Int. 2020; 30:86-93. DOI
  29. Parvizi J, Tarity TD, Slenker N. Proximal femoral replacement in patients with non-neoplastic conditions. J Bone Joint Surg Am. 2007; 5:1036-1043.
  30. Kamal A, Dong RJ, Shah R. Management of periprosthetic fractures of knee arthroplasty with revision surgery. J Orthop. 2020; 22:118-123. DOI
  31. Herrera DA, Kregor PJ, Cole PA. Treatment of acute distal femur fractures above a total knee arthroplasty: systematic review of 415 cases (1981-2006). Acta Orthop. 2008; 79:22-27. DOI
  32. Gondalia V, Choi DH, Lee SC. Periprosthetic supracondylar femoral fractures following total knee arthroplasty: clinical comparison and related complications of the femur plate system and retrograde-inserted supracondylar nail. J Orthop Traumatol. 2014; 15:201-207. DOI
  33. Kiluçoğlu OI, Akgül T, Sağlam Y, Yazicioğlu O. Comparison of locked plating and intramedullary nailing for periprosthetic supracondylar femur fractures after knee arthroplasty. Acta Orthop Belg. 2013; 79:417-421.
  34. Aldrian S, Schuster R, Haas N. Fixation of supracondylar femoral fractures following total knee arthroplasty: is there any difference comparing angular stable plate fixation versus rigid interlocking nail fixation?. Arch Orthop Trauma Surg. 2013; 133:921-927. DOI
  35. Horneff JG, Scolaro JA, Jafari SM. Intramedullary nailing versus locked plate for treating supracondylar periprosthetic femur fractures. Orthopedics. 2013; 36:e561-566. DOI
  36. Vaishya R, Thapa SS, Vaish A. Non-neoplastic indications and outcomes of the proximal and distal femur megaprosthesis: a critical review. Knee Surg Relat Res. 2020; 32:18. DOI
  37. Darrith B, Bohl DD, Karadsheh MS. Periprosthetic fractures of the distal femur: is open reduction and internal fixation or distal femoral replacement superior?. J Arthroplasty. 2020; 35:1402-1406. DOI
  38. Cannon SR. The use of megaprosthesis in the treatment of periprosthetic knee fractures. Int Orthop. 2015; 39:1945-1950. DOI
  39. Bottlang M, Doornink J, Lujan TJ. Effects of construct stiffness on healing of fractures stabilized with locking plates. J Bone Joint Surg Am. 2010; 92:12-22.
  40. Ries ZG, Marsh JL. Far cortical locking technology for fixation of periprosthetic distal femur fractures: a surgical technique. J Knee Surg. 2013; 26:15-8. DOI
  41. Moazen M, Leonidou A, Pagkalos J. Application of far cortical locking technology in periprosthetic femoral fracture fixation: a biomechanical study. J Arthroplasty. 2016; 31:1849-1856. DOI
  42. Evans S, Laugharne E, Kotecha A. Megaprostheses in the management of trauma of the knee. J Orthop. 2015; 13:467-471. DOI
  43. Patel NK, Whittingham-Jones P, Aston WJ. Custom-made cement-linked mega prostheses: a salvage solution for complex periprosthetic femoral fractures. J Arthroplasty. 2014; 29:204-209. DOI
