Osteosynthesis of Ideberg type III glenoid fracture with retroclavicular cannulated percutaneous screw

Ospedale Santa Maria Annunziata, Azienda USL Toscana Centro, Bagno a Ripoli, (FI), Italy
Ospedale Santa Maria Annunziata, Azienda USL Toscana Centro, Bagno a Ripoli, (FI), Italy
Ospedale Santa Maria Annunziata, Azienda USL Toscana Centro, Bagno a Ripoli, (FI), Italy
Ospedale Santa Maria Annunziata, Azienda USL Toscana Centro, Bagno a Ripoli, (FI), Italy
Ideberg glenoid fracture scapular fracture shoulder

Abstract

In this article we report a 74 year old patient with Ideberg-type III fracture who was treated with indirect reduction and fixation. The patient was a sportive biker who suffered from a high energy trauma (road accident). X-ray revealed a scapula fracture, and only after a CT-Scan we could confirm the fracture type (Ideberg-type III glenoid fracture). The patient was operated and re-evaluated at follow-up. During the surgery we prefered not to access intra-articular due to the low joint involvement. He was able to resume his daily activities at two months postoperatively. At three months ASES Score was 91.5; Constant Score was 71 (vs 96 of unaffected arm). The patient revealed to be satisfied with the treatment, moreover the clinical results are encouraging in view of further improvements in the following months.

Introduction

Fractures of the scapula represent 0.4-0.9% of all fractures and approximately 25% involve the glenoid articular surface 1. Men in the fifth decade of life after high-energy trauma are most often affected, frequently in association with other injuries of the rib cage, upper limb and pelvic ring. Instead, women are generally affected in the 7th decade of life following low-medium energy trauma 2.

The main cause of this type of fracture is the impact of the humeral head against the glenoid, sometimes associated with dislocation of the gleno-humeral joint. More rarely they are due to direct trauma or muscle contraction avulsions typical of seizures or electric shocks 3.

Radiological study involves X-rays in antero-posterior projection and according to Neer I, in some cases an axillary x-ray may also be useful. On the other hand, CT and 3D reconstructions with subtraction of the ribs and the proximal humerus are essential.

Ideberg type III fractures (Fig. 1) are injuries involving the glenoid with superior extrarticular extension beyond the base of the coracoid 4. They are often associated with damage to the acromioclavicular joint, configuring a double lesion of the superior shoulder suspensory complex (SSSC) 5. In addition, possible injuries to the suprascapular nerve have been described in the literature 6.

Treatment of these fractures is conservative if they are undisplaced. In the literature, however, there is no precise consensus on the degree of displacement necessary to indicate surgical treatment. Kavanagh proposed displacement of the fragments over 2 mm 7, while Mayo over 5 mm 8.

Herein, we describe a case of an Ideberg type III glenoid fracture treated surgically with a reduction performed through a deltopectoral approach and fixation with a cannulated screw through a minimally invasive retroclavicular approach.

Case report

A 74-year-old man suffered mixed trauma to his right shoulder following a fall on a bike. When he arrived at our emergency room, X-ray and CT scan of the shoulder showed a displaced Ideberg type III fracture of the glenoid, associated with a grade 3 acromioclavicular dislocation. The fracture marginally involved the upper portion of the glenoid; however, in accordance with the biomechanical studies conducted by Pècora et al. 9, it is precisely in this area that the greatest pressure is exerted by the head of the humerus when the limb is at 60° of abduction. Despite the minimal joint involvement, we therefore decided to proceed with surgical treatment.

Methods

Pre-intervention

The surgery was performed under general anesthesia without peripheral nerve block so as to evaluate, immediately after surgery, the possible presence of nerve damage. The patient was positioned in a beach-chair position and the arm was left free in order to facilitate the reduction procedures. The image intensifier was positioned behind the patient in order to perform antero-posterior (AP) scapula projections. After carrying out the preliminary radiographic checks, a sterile field was set up on the left shoulder (Figs. 2-3).

Surgical procedure

The proximal part of the deltopectoral approach was involved. The coracoid process was identified and a 1.6 mm Kirschner (K) wire was inserted into it. We then used the K wire as a joystick with the aim of obtaining indirect reduction of the fragment. Considering the marginal involvement of the superior articular surface (< 10%), we preferred not to perform capsulotomy in this case. We then used the Neviaser portal 10 for osteosynthesis using a 4 mm cannulated screw. We then performed the final X-Ray of the osteosynthesis which were satisfactory with a stable fracture fragment in the shoulder and elbow mobilization tests. At the end of general anesthesia, we evaluated the active abduction and external rotation movements which were complete and pain-free.

Post-operative treatment

In the post-operative phase, we applied a universal shoulder brace to the patient with the possibility of removing it 3 times a day to perform passive mobilization of the shoulder (pendulum) and passive mobilization of the elbow in flexion-extension and pronation-supination with the prohibition of lifting weights. At 4 weeks, the patient was able to remove the shoulder brace and start activities for recovery of complete passive range of motion (ROM) and isometric reinforcement of the rotator cuff and deltoid muscle (Fig. 4).

Results

At 14 weeks, we calculated the ASES score (Tab. I), constant shoulder score (Tab II) and UCLA score (Tab. III) to assess outcome. The patient almost completely recovered shoulder ROM in all planes. He was able to lift in abduction up to 0.75 kg with progressive recovery, which negatively affected his ability to perform recreational and work activities. He reports occasional pain which however does not interfere with rest, normal daily activities or personal hygiene. Overall he is very satisfied with the result obtained with surgical treatment. At X-ray follow-up, we observed the loss of reduction of the acromioclavicular joint which did not affect the patient’s normal daily activities (Fig. 5).

Discussion

The approach described allows for reduction and osteosynthesis to be performed without the need to open the joint capsule. This avoids detachment of the subscapularis tendon and reduces the possibility of any infectious agents penetrating the joint. The suprascapular nerve, due to its course through the suprascapular notch, is likely to remain incarcerated within the fracture after closed reduction; for this, its functionality must be carefully evaluated both before and immediately after the intervention. It is therefore recommended not to proceed with locoregional anesthesia of the brachial plexus so as to be able to test the functionality of the supraspinatus and infraspinatus muscles in the immediate postoperative period. It is also advisable in the immediate pre-operative period to check the positioning of the image intensifier for correct visualization of the fracture gap in order to reduce the duration of the surgical procedure. The clinical result on our patient was excellent overall. The modest results of the UCLA Score and the constant shoulder score are attributable to the lack of strength in anterior flexion and abduction which, however, are progressively recovering.

Conclusions

We believe that the deltopectoral approach associated with minimally invasive retroclavicular access may be a valid alternative for treatment of Ideberg type III glenoid fractures involving the marginal articular surface. This allows to obtain good reduction and stable osteosynthesis with a minimum invasiveness.

Acknowledgement

None.

Ethical consideration

The institution approved the human protocol for this investigation; all investigations were conducted in conformity with ethical standards of the institutional and national research committee and with the 1964 Helsinki declaration and its later amendments. All patients have given their informed consent for participation and there is no financial interest to report.

Funding

None.

Conflict of interest

None.

Figures and tables

Figure 1.Ideberg classification of glenoid fractures.

Figure 2.3D CT scan.

Figure 3.Sagittal CT scan.

Figure 4.Post-operative X-Ray.

Figure 5.14 weeks follow-up.

ASES score
Usual work Retired
Usual sport/leisure activity None
Shoulder pain at night No
Use of pain killers No
Use of strong pain killers No
How many pills on an average day 0
Intensity of pain 1
Difficulty to put on a coat Not difficult
Difficulty to sleep on the affected side Not difficult
Difficulty to wash back Not difficult
Difficulty to manage toiletting Not difficult
Difficulty to comb hair Not difficult
Difficulty to reach high shelves Not difficult
Difficulty to lift 4,5 kg above sholders Unable to do
Difficulty to throw a ball overhead Somewhat difficult
Difficulty to do usual work Somewhat difficult
Difficulty to do leisure activity Not difficult
Result 91.5
Table I.ASES score.
Constant shoulder score Affected arm Unaffected arm
Pain during past 4 weeks None None
Unaffected sleep Yes Yes
Full recreation No No
Full work No No
Arm position Above head Above head
Strenght of abduction 7-9 Pounds > 24
Forward flexion 151°-180° 151°-180°
Lateral elevation 151°-180° 151°-180°
External rotation Hand on top of head Head on top of head
Internal rotation T12 T12
Result 71 96 Difference 25
Table II.Constant shoulder score.
UCLA score
Pain during the past 4 weeks Occasional and slight
Function Most domestic chores, shopping and driving
Active forward flexion 150°
Strength of forward flexion Grade 4
Satisfaction of patient Satisfied and better
Result 28
Table III.UCLA score.

References

  1. Bartoniíˇcek J, Tuˇcek M, Klika D. Pathoanatomy and computed tomography classification of glenoid fossa fractures based on 90 patients. Int Orthop. 2016; 40:2383-2392. DOI
  2. Baldwin KD, Ohman-Strickland P, Mehta S. Scapular fractures: a marker for concomitant injury? A retrospective review of data in the national trauma database. J Trauma. 2008; 65:430-435. DOI
  3. Tornetta P. Rockwood and green fractures in adults. Walters Kluwer: Philadelphia; 2020.
  4. Ideberg R, Grevsten S, Larsson S. Epidemiology of scapular fractures. Incidence and classification of 338 fractures. Acta Orthop Scand. 1995; 66:395-397. DOI
  5. Cole P, Gauger ME, Schroder LK. Management of scapular fractures. J of Am Acad Orthop Surg. 2012; 20:130-141. DOI
  6. Solheim LF, Roaas A. Compression of the suprascapular nerve after fracture of the scapular notch. Acta Orthop Scand. 1978; 49:338-340. DOI
  7. Kavanagh BF, Bradway JK, Cofield RH. Open reduction and internal fixation of displaced intra-articular fractures of the glenoid fossa. J Bone Joint Surg Am. 1993; 75:479-484. DOI
  8. Mayo KA, Benirschke SK, Mast JW. Displaced fractures of the glenoid fossa: results of open reduction and internal fixation. Clin Orthop Relat Res. 1998; 347:122-130.
  9. Pécora JOR, Neves Junior AT, Roesler CRM. Glenoid track evaluation by a validated finite-element shoulder numerical model. Orthop Traumatol Surg Res. 2020; 106:735-742. DOI
  10. Neviaser TJ. Arthroscopy of the shoulder. Orthop Clin North Am. 1987; 18:361-372.
